A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 134

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 134
Figure 76.—Frames in Position. … Figure 77.—These Ways Were Lowered While the Ship Was in Frame. 132 COURSE IN WOODEN BOAT AND SHIP BUILDING is performed dt one time. Figures 80 and 81 showthe heads of the same frames. Keelsons.—The keelson timbers are eight innumber, as shown on the midship section, Figure47. These are put in in…

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
