A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 171

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 171
Figure 114.—Scarfiog Timber witli an Adze. 168 COURSE IN WOODEN BOAT AND SHIP BUILDING … Figure 118.—Calkicg Mallet. Figure 119.—Ship Auger Bits. HAND TOOLS 169 siderably from the ordinary axe used for chopping.The blade is wide and is sharpened by beveling-one side more than the other, somewhat like achisel. Both blade and handle are offset, the wholeform and hang being adapted to…

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
