Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)
American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 175
arms, but serves as a filletaround the hub of the wheel. The blocks for the teeth are next fitted in place, either asillustrated in Fig, 247, or in the form of alternate blocks andstrips as was shown for the spur gear, Fig. 237. After all theblocks are in place, the wheel must be put in the lathe…
Mechanical engineering -- Dictionaries
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
