A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 37

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 37
tely shaped and fitted, the stock to be usedcan be lined up to these moulds and fitted withoutmuch trouble. They can now be riveted or boltedtogether. RABBETING It is usual and proper to cut the rabbet, or recessin the stem and stern to receive the ends of theplanking, before raising them. The… … STEM AND STERN CONSTEUCTION

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
