A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 54

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 54
re-moved from the form, Avhen they can be resawedand planed to the required thickness. Line up thetimbers from the moulds and number each onefor ready identification. DIAGONAL LINES The diagonal lines are dra-\vn in on the bodyplan. Figure 3, standing as nearly square as pos- FUTTOCKS AND FRAMES 51… … Figure 23.—Bending Timbers. as 1st, 2nd, 3rd, etc., diagonals, and give thestations or surmarks of the ribbands, which areplaced around the timbers to give support to thevessel while in frame. 52 COURSE IN WOODEN BOAT AND SHIP BUILDING SHCER Line SheerLine.
