disks. Mr. Wimshurst has constructed the diagram (Fig. 360) Fig. 360, … which shows the distribu-tion of the electricit} uponthe plate surfaces when themachine is fully excited.The inner circle of sia:nscorresponds with the elec-tricit} upon the front sur-face of the disk. The twocircles of signs betweenthe two black rings referto the electricity betweenthe disks,…
