Experimental science. Elementary, practical and experimental physics (1890)
Hopkins, George M. (George Milton), 1842-1902 · New York, Munn & co. · leaf 463
Principle of TangentGalvanometer. 440 EXPERIMENTAL SCIENXE. tog-ether, have a resistance of one ohm. The coils, c, b, a,have a combined resistance of lo ohms. The coil, d, togetherwith the preceding, offers a resistance of 50 ohms, and thecombined resistance of all of the coils, c, d, c, b, a, is… … Tangent Galvanometer. until it reaches one of the smaller switch plates, which isconnected with the plate. A, by the plug. In the presentcase the plug is inserted between the plate marked i andthe plate. A, causing the current to flow from the bindingpost,/, through the coils, a, b, and plate. A,…
Physics · Lantern projection · Electric apparatus and appliances
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
