face in an oblique plane. AB is measured on all the three perpendicular planes.Note that the eyes in relation to each (eye 2, 3, and 5)all occur on the same arc, as also do the three M.P.s. Perpendiculars to the Six Planes 135 The perpendiculars to the serenth plane, parallel tothe picture, are… … Fio. 103. solutions of examination questions supply sufficientexamples. Fig. 103 is added to show the way the working linesof the geometry, by which the V.L.s, M.P.s, and eyesare obtained, conspire to obliterate the picture and con-fuse the student! 136 Perspective 46.A Few Hints to Draughtsmen.…
