ws a shadow upon the slopingback. We draw from the light a line parallel to AA—that is vertically—and where it cuts the sloping plane isthe point from which the shadow radiates. To obtainthis point we draw a line, M, through the seat of thelight on the G-.P., to cut the intersection of ground… … the intersection, and it comes down towards 0. We 152 Perspective drop our light down to this line and gain E.S.i, whichis the point to which the shadow of AA will radiate. Wethus easily obtain AA, the shadow. The shadow of the vertical BD on the narrow uppersurface of the plinth requires one to…
