rallelto the picture, and the slanting bank will have its linesnot vanishing, but drawn with the set square. FB is sucha line. We therefore draw from the point, which is 264 Perspective 6 feet above B, a slanting line parallel to EB. Thisgives us E and EF, 6 feet high, for in parallel perspectiveB… … Fia. 206—The problem solved. transfer H back over A, which gives the correct heightof the man. Assuming that the smoke is following a level course,It is vanishing on the H.L. somewhere on the left. Bycontinuing the dotted lines in the smoke this V.P. isfound, and the flag made to vanish there also.…
