206—The problem solved. transfer H back over A, which gives the correct heightof the man. Assuming that the smoke is following a level course,It is vanishing on the H.L. somewhere on the left. Bycontinuing the dotted lines in the smoke this V.P. isfound, and the flag made to vanish there also.… … &B Fia. 207.—Diagram Q. 12. centre of vision, and distance of the eye from the pictureare given. Find the vanishing point of the swns rays anddraw the shadows of line B and of the doorway. (15 marks.) 266 Perspective Thds drcmmg will occupy a spaoe 15 inches wide and10 J inches high, in the…
