n per sq. ft. tension at A.Q. 74. A division wall in the above tank is 1 ft. thick at top and 3 ft. thick atbottom. Find the maximum tension and compression when one side is full andthe other empty. EXAMPLES FOR PRACTICE 161 Answer. See Pig. 475. The stresses will be W , M 1920 . 1920 X 1-11 A±S =… … SecC. area above AB= SOO scf ft. rfg. 476 r/q.477
