sign finds its architecturalapplication to reinforced concrete, of which there are examples withand without hinges. We have already in Lecture XI. dealt with combined longitudinal andtransverse stresses, in Lecture XII. with pillars or stanchions eccentricallyloaded, and in Lecture XVIII. with… … F/g S06 the formulae for obtaining the different elements, as it may be usefulin connection with other matters. These are shown upon Fig. 506, and the formula will be asfollows :— Chord of 1 arc = V(i span)^ + rise^ Eadius = ja4^5)!+risel^ L rise J cos I riseJ ^ _ , _ (chord of whole arc)^2 X…
