Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)
Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 150
A PORCH CHAIR Material Required 6ACK O H Front verticals, 2 pieces, % by 3 by 14 inches,inches, S-4-S. Back verticals, 2 pieces, % by 6 by 33 inches,S-4-S. Bases, 2 pieces, % by 4i/^ by 21% inches, S-4-S. Side rails, 2 pieces, % by 2% by 16 inches,S-4-S. Front rail, 1 piece, % by 2 by 17 inches,… … PLATE 136 A—HOW TO MAKE A PORCH ARM CHAIR Material Required Front verticals, 2 pieces, % ^7 3^/4 by 271/^ Back rails, 2 pieces, % by 5 by 19% inches, inches, S-4-S. S-2-S. Back verticals, 2 pieces, % by 4% by 34y2 Back rails, 1 piece, % by IVo by 19% inches, S-4-S. S-2-S. Bases, 2 pieces, Vs oy f/^…
