Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)
Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 187
HANDY CLAMP FOR SAW SHARPENING The side pieces are of 2 by 4s about four feetlong, ripped to form the shape. The jaws are 1by 4 inches, 26 inches long, and are shaped to fitinto the side pieces. The bolts adjust the open-ing in the side pieces so that the jaws will notclamp down too far. These jaws… … ARRANGEMENT FOR DUMB WAITERS Hand elevators, or dumb waiters, are of variouspatterns or designs; yet, in general the idea is thesame in all and the drawings herewith will showthe methods of finishing the elevator shafting, ar-ranging the sliding doors, etc. li f-\J-. T li
