Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)
Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 35
PLATE 23—ROOF DORMER WINDOWS 3—Sloping roof dormer. The simplest kind of 4—Gable end dormer, appropriate on steep-a dormer and very satisfactory if the main roof roofed buildings. All of these formers are wellrises high enough to allow it. suited for both new and remodeling work. 32 … PLATE 24—CORNICE CONSTRUCTION FOR FRAME BUILDINGS 1—Narrow box cornice; 2—Simple open rafter galow cornice with ornamental rafter ends; 9— cornice; 3—SofSt nailed direct to rafter ends; Square box cornice with show rafters; 10—Curved 4—^Box cornice bracketed; 5—Wide box cornice; cornice with…
Building
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
