Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)
Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 82
Pici.iFs: FROW. PLATE 70—OUTWARD OPENING CASEMENT—ORDINARY CONSTRUCTION Arrangement ordinarily used in frame dwell-ings. Fig. 150, section through window head.Note flashing of tin, or in better work, copper.Fig. 151, section through window jamb. Notethat inside atop bead is hollowed at H to form…
