Young, George, jr, Baxter, Hubert Eugene, joint author · New York, Macmillan · leaf 24
Isometric Projection Fig. 6 For a more extended treatment of isometric projection and other similarmethods, see Chapter XIII. I, §3] PURPOSE AND SCOPE ings have been used, in general, though Cavalier projectionsor perspective drawings have been substituted in a few cases. 3. The Theory of Plan… … OrthographicFig. 7 Projeclion bounding lines. Any line is determined by any two of itspoints. Hence the size and shape of any object are fixed by the ^interrelations of its limiting points. For example, in Fig. 7 —^the roof surface A is defined by the lines cib, be, cd, and da.These lines in turn…
Geometry, Descriptive
