or reduces greatlythe amount of labor in making stability calculations, and for this reasonis now used practically to the exclusion of numerical methods, by navalarchitects, who have much stability work to do. Fig. 17 is a diagram ofa common form of the instrument. The integrator runs on a steel… … FIG. 17. 42 ELEMENTS OF YACHT DESIGN In using the integrator, the track is first set parallel to and at the cor-rect distance from the axis of the figure b}- means of the gauges G and G.In figure 17 the instrument is placed for finding the righting arm of ayacht at 30 degrees inclination. The line…
