A manual of naval architecture for the use of officers of the Royal Navy, officers of the Mercantile Marine, yachtsmen, shipowners, and shipbuilders (1894) White, W. H. (William Henry), Sir, 1845-1913 · London : J. Murray · leaf 431
weredowelled. This was an exceptional arrangement, however, thealmost universal plan adopted where two pieces of timber had to bejoined end-to-end, in order to form a tie, being to scarph or over-lap the ends in some fashion more or less complicated and expensive. 406 NAVAL ARCHITECTURE. [chap. x.… … tabling and the sunken recesses into which the tabling fits.Fig. 136 shows the two parts in place, with the fastening bolts whichassist the tabling in resisting tensile strains tending to open thescarph. The plan was an excellent one, but necessitated considerable FIG. 137. b @ I / ©M o *j i PUj… Naval architecture
