Lake ship yard methods of steel ship construction (1907)
Curr, Robert · Cleveland : The Marine review · leaf 113
er which r ° o o ; o P o \ 0 o 0 o o 0 -fyq^loi, o 1*:.. A_° o o 6 i o o 102 LAKE SHIP YARD METHODS OF they would be bolted to the center keelson and faired up with rib-bands as explained previously. All the parts outside of the centerkeelson and frames, floors and reverse bars would be lifted from… … work and boiler saddles as per plans, Figs. 107 to 109, in Scotland.On the lakes this work as shown would cost only half of that amount. SHELL PLATING AFT Fig. 110 shows the expanded shell plating aft from the keel to thebulwarks. Keel plate, No. 21, is fitted in two pieces the butt coming wherethe…
Naval architecture · Ships, Iron and steel
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
