Lake ship yard methods of steel ship construction (1907)
Curr, Robert · Cleveland : The Marine review · leaf 118
flanges are measured parallel to the lines ELG for the top and HFKfor the bottom. LL> shows the width of the top flange and FFi thebottom flange. The projecting parts beyond EH and GK representthe flanges for the connection to the transom frame. After the plateis sheared to the shape shown by…
Naval architecture · Ships, Iron and steel
