o offsetthis, the iron table is alittle apt to be stickylike an iron plane, anddoes not keep as cleanas a good hardwoodtable. Fig. 3 will illustratetwo ways of roughingout small core-boxes onthe buzz saw. I haveheard it asserted that itwas possible to cut asmall core-box for astraight round core… … Fig. 3- 68 PATTERNMAKING. a & be the top of saw-table; set the saw to the right height,or one-half the diameter of the core-box. A part of thesaw, represented by the arc d e, is now above the saw-table.We must now find the angle at which the box must bepassed over the table, that the saw, which…
