Lake ship yard methods of steel ship construction (1907)
Curr, Robert · Cleveland : The Marine review · leaf 124
ips. Fig. 122 shows the starboard side of the after deck house. Onemold serves the purpose of marking all the holes for stiffness and theholes for the pilasters. The top and bottom angles having a uniformpitch of rivet holes require only two molds for marking the whole sideof the plating. All that… … 114 LAKE SHIP YARD METHODS OF
Naval architecture · Ships, Iron and steel
