uces simi-lar movements in the other two Tillers.QQQQQQQQ The Stations of the Timber Heads and Rails. RR The Bits to which the Cables are fastened when the ship is at anchor.SS Th^ Bumpkins to which the Tacks of the Foresail are ex-tended, according to the Tack on which the ship stands. Figure… … i 6 I STEAM NAVIGATION. 29 Figure 6.A View of the Edinburgh under sail, and the Wheels working. Figure 7. Another View of her under sail, with the Wind on the quarter, and theWheels raised out of the Water. Figure 8.A Plan of the Wood Work of the Wheel when seen edgeways. ; Figure 9.ji Plan of the…
