Lake ship yard methods of steel ship construction (1907)
Curr, Robert · Cleveland : The Marine review · leaf 130
ne side of the bulkhead, the process beingsimilar to the after deck house in laying off the pilasters and stiffeners.. Fig, 131 shows the plan of the top of the forward deck house, thebeams, top angles and deck plating are laid off similarly to the afterdeck house. Fig. 132 shows the forward end of… … —//<?. ^ 3- 120 LAKE SHIP YARD METHODS OF
Naval architecture · Ships, Iron and steel
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
