Lake ship yard methods of steel ship construction (1907)
Curr, Robert · Cleveland : The Marine review · leaf 131
Fig, 129a. … STEEL SHIP CONSTRUCTION 121 are laid out by the same process as Figs. 122 and 123 of the afterhouse. Fig. 135 shows the after end of the pilot house and Fig. 136 theport and starboard sides of same. The foundation angle is shownon the top of the fore house for the pilot house and represents…
Naval architecture · Ships, Iron and steel
