Lake ship yard methods of steel ship construction (1907)
Curr, Robert · Cleveland : The Marine review · leaf 32
lange of this angle are obtained from theshell mold, b. Fig. 13. Fig. 29 shows mold for plate at side of arch; two plates for eacharch are marked from this niold. Fig. 30 shows half mold for the center plate of arch. The moldfits to the center line and the holes near same are for bracket… … 22 LAKE SHIP YARD METHODS OF
Naval architecture · Ships, Iron and steel
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
