s the distance NXS, Fig. 77, the bevel-ing edge at deck. 68 LAKE SHIP YARD METHODS OF To obtain the beveling edge at the transom floor a parallel line toMN, Fig. 77, is run in the width of the transom frame, MN represent-ing the heel of the transom frame. By measuring from the 2S-ft. line to the… … By drawing a line from the knuckle X4 to X6 the intersection ofthe line MN is the bevel which in this case is shut bevel at the transomframe. The line d shows open bevel to the amount of between b andd. The bevel line shown at d. Fig. 77, is transferred to a boardasshown by Fig. 77a. The bevel line…
