Mechanical and marine engineering science ... Specially written as a handbook to the Board of Trade examinations for extra-first-class engineers (1909)
Somerscales, A. N · Glasgow : J. Munro; London, Simpkin, Marshall, Hamilton, Kent · leaf 206
ect of a number of equal radial forces acting uponeach unit in the length of a semi-circular arc, -when resolved in adirection at right angles to the diameter is equal to a single forcemultiplied by the num,ber of units in the diameter. Figure 73. In the case of a fly-wheelthe principle means that… … Fig. 73. 204 CENTRIFUGAL FORCE. and each bolt must carry one-fourth of this force, which, at 5000lbs. per square inch, requires Area of each bolt = _5£_£ = 13-052 sq. in.5000 and diameter of bolts = 4*07 inches. 5. Assuming the sectional area of the rim of wheel in above example to be 76 sq.…
Naval architecture
