ve, keeping in mind the fact thatthe maximum opening for steam and exhaust, as well as the lead,■are virtually twice what the diagram gives. Litiking up. — Anapproximate diagram fora link motion with thesliding block at any inter-mediate position may bedrawn as follows:—Infigure 109, A and B arethe… … Fig. 109. THE VALVE DIAGRAM. SOI* with the other rod. Now divide the link centre line db and also the-straight line between eccentric centres AB, into the same number ofequal parts (6 in figure 109). Let the gear be linked up until theblock comes into position d. Take the corresponding position…
