Text-book of theoretical naval architecture (1889)
Attwood, Edward L. (Edward Lewis), 1871- · London, New York [etc.] Longmans, Green, and Co. · leaf 106
tion aship is inclined, transversely,longitudinally, or in any interme-diate direction, through a smallangle, the line of intersection ofthe new water-plane with theoriginal water-plane must alwayspass through the centre of flotation. For transverse inclinationsof a ship the line of intersection is… … ■ Plan.-— Fig. 47, 96 Theoretical Naval Architecture. Shift of the Centre of Gravity of a Figure due tothe Shift of a Portion of the Figure.—Let ABCD,Fig. 48, be a square with its centre at G; this point will alsobe its centre of gravity. Suppose one corner of the square EF is taken away and…
Naval architecture
