A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 69

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 69
66 COURSE IN WOODEN BOAT AND SHIP BUILDING … niDDLE LINE FUTTOCICS AND FRAMES 6T and floors, so that a compact union may be formedthroughout the system. It is placed immediatelyabove the keel, lying upon the upper part of thefloors as far as they extend, and resting fore andaft against the deadwood. If the timber will per-mit, it should be…

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
