oss-curves is shown inFig. 80 for displacements between 3000 and 5000 tons atangles of 15°, 30°, 45°, 60°, 75°, and 90°. At any intermediatedisplacement, say at 4600 tons, we can draw the ordinate andmeasure off the values of GZ, and so obtain the ordinatesnecessary to construct the ordinary curve… … 15. 30. 4-5. 60. 75. Degrees of Inclination. Fig. 81. of stability for a vessel at displacements of 1500, 2000, 2500,and 3000 tons. These are placed as shown in perspective,Now, through the tops of the ordinates at any given angle wecan draw a curve, and this will be the cross-curve of stabilityat…
