Barrows, F. W. (Frank Wilson), b. 1853 · New York, N.W. Henley Pub. Co. · leaf 102
ust change the slide to the angle of brokenline h, I, k, mark off on one of the sides, already cut, thelength of side, as from i to k; then, by adjusting the stopon sUde so that the saw will cut to this point, you can sawtwo more sides on each head, as b and /. Go through thesame process for each… … Fig. 24. side j,l parallel with the side of head you propose to cutwhen the head is laid against the slide in position for cut-ting. Fasten a piece on this gauge at n to bring all of theheads to be sawed into the same position. Use the fence,
Patternmaking
