Barrows, F. W. (Frank Wilson), b. 1853 · New York, N.W. Henley Pub. Co. · leaf 155
, Fig. 54. This piece should … Fig. 54- be long enough to reach across the flanges, and should becut into them half their thickness. The side of this piecetoward centre pin is then to be cut away, as shown bydotted hnes between d and n in Figs. 55 and 56. The sides of the crosshead are then gotten out and fas-tened together by…
Patternmaking
