ilar to Fig. 19, but these are hardon the lathe centres, especially thetail centre when it isnt in line withthe spindle, although they may beused at the spindle end in connectionwith some form of lathe-dog for driv-ing the work. In all cases a woodencentre piece at tail end, with a centrelike Fig.… … Fio. 19. THE LATHE. 91 for tail centre. This is a poor way. How are you goingto square off the end of pattern for face-plate so that it willrun exactly true ? that is, supposing the tail centre to be inline with spindle. If it isnt in line, it wont make anydifference whether the end is square with…
