a small pipe, the cylindersare filled with water, and in each cylinder an air-tight verticalplunger works. If G and c are the two plungers and A, a the areasof the sections of the plungers, when a force of P lbs. weightis applied to the smaller plunger it produces a pressure of — lbs. weight per… … Fio. 8. On the down stroke of the smaller plunger the valve on the right isdisplaced, and water is forced into the large cylinder a? the largeplunger rises. On again raising the small plimger the valve on theright closes and the large plunger is kept in its position while thevalve on the left is…
