by Dobrowolsky for securing a concentrationor a stiifening of the field towards the middleof the pole face. It consisted of connectingall the poles together by an iron ring, whichproduced a large leakage flux across the poletips, so rendering them highly saturated andunable to carry the main flux,… … Fig. 1.—Comb Poles lamination is sometimes cut short of the poleface (see fig. 1), so that the fiux-density inthe air gap at that region is doubled. Some-times only the pole tips are cut away in thismanner (see fig. 2); this, however, being done
