How to read plans and take off bills of materials. (1917)
William A. Radford · Radford Architectural Company · leaf 52
^■%FLOORlfSG 8X3 JOIST S* Boards x2 Strips … ZtVq Wall BoardFig. 155—A shallow floor for stair platform. difference and makes the space usable. It is prob-lems like this that test out the thinking power ofthe builder. Half Timber Construction.In cases like that illustrated in Fig. 140, wherehalf timber construction work is shown, the…
Building materials, house plans · House contruction · Lumber
Internet Archive · Building Technology Heritage Library · Public Domain Mark 1.0. Free to use for anything.
