the coil an emf in phasewith the primary emf. Such a coil will now1)6 at right angles to the circuit to which itds connected. In a similar manner a coil atlight angles to the armature circuit, i.e.the circuit parallel to the stator axis, if con-nected in series with that circuit, will alsoserve to… … Fig. 6—Fynns Compensated Slinnt-induction Motor combine the compensated shunt-inductionmotor with the ordinary or squirrel-cageform. An example of this is Fynns formof compensated shunt-induction motor (B.P.,22,712, 1902), in one form of which, in addi- tion to the ordinary drum winding on…
