The microscopy of vegetable foods : with special reference to the detection of adulteration and the diagnosis of mixtures (1906)
Winton, Andrew Lincoln, 1864-1946, Moeller, Josef, 1848-1924 · New York : John Wiley & Sons · leaf 495
Fig. 390. Strawberry (Fragaria vesca). Leaflet, natural size. (Moeller.) base and hairy underneath (Fig. 390). There are as many veins asteeth, each vein ending in a tooth. The Epidermis (Figs. 391 and 392) of both sides is similar, except that 472 ALKALOIDAL PRODUCTS. the cells on the under side… … Fig. 391- Strawberry. Upper epidermis of leaf. (Moeller.)
Plant anatomy · Food adulteration and inspection · Microscopy
