would cause the relay to let go of its armature, and thus breakthe circuit at point h. The white lamp remains lighted, therefore,as long as the call on its A trunk is unattended to. The first act of the A operator on seeing this light is to throwher lever corresponding to that light into its… … FIG. 219.—TABLE OF A BOARD. be noted that these keys on the A operators board are the onlymeans afforded to any operators for communicating with sub-scribers. The operation of this key breaks the circuit of the whitelamp at the points, c f. As soon-as the listening key is thrown againinto its…
