Martin, Louis Adolphe, 1880- · New York, J.Wiley & Sons, Inc.: [etc. etc.] · leaf 65
the loadings shown in Figs. 18 and 19 actingsimultaneously. 44 ■ MECHANICS OF MATERIALS Bending Moments by Means of the Funicular Poly-gon. — The bending moments due to concentrated loadscan be found graphically by means of the funicularpolygon constructed for these loads. In Fig. 27 areshown the…
Mechanics
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
