AMS Horizontal Shear. — So far the stresses due to purebending only have been considered. These stresses werefound to be normal stresses (tension and compression) 64 MECHANICS OF MATERIA varying according to the straight-line law, and pro-portional to the distance of the fiber from the neutralaxis.… … Fig. 35 In Fig. 35 (a) let AB be any section of a beam, DC asection at a distance dx from the first, HG the neutralsurface, and MN any plane parallel to the neutral STRESSES IN BEAMS 65 surface. The beam is assumed to be of rectangular sec-tion and b inches wide. Fig. 35 (b) shows the elementAMND…
