Martin, Louis Adolphe, 1880- · New York, J.Wiley & Sons, Inc.: [etc. etc.] · leaf 81
shownin the separate poly-150* gons of forces aboveit. In stress diagramsthe arrow-headsupon the hnes show-ing the stresses in themembers should beomitted, for in thecomplete figure eachof these hnes wouldhave two arrow-heads in oppositedirections. To discover fromthe stress diagramwhether…
Mechanics
