candescent lampsare almost always connected in multiple. In Fig. 2 if each of the7 lamps shown takes 1 ampere of current the total current at A 131 10 UNDERWRITERS REQUIREMENTS and at B will be 7 amperes, while at C and at D it will be 2 amperes.Series Connection. When a number of devices are so… … Fig. 7. Effects of a Short-Circuit in Wires Under Floor total current is no more and no less than the current in each con-nected series device. Shunt. A shunt is a by-path between two points so connectedthat part of the current will traverse it. The division of the totalcurrent between the main…
