Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 444
t elements. The interaction between these fields and theopposing fields of the currents induced in the moving element causesit to turn. In an induction meter the secondary consists of a lightaluminum disk. The shunt winding, consisting of a large numberof turns of fine wire wound on a laminated… … 360 Fig. 98. Two Alternating Currents in Quadrature Shown in Wave Form turns of comparatively heavy wire, has low self-induction and con-sequently the current in the series coils will be approximately inphase with the line voltage; thus the magnetic field produced bythe shunt winding will be…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
