the side of each arm,Fig. 201, are seen the seatingsand bolt-holes for attaching thecommutator-hub and the rimwhich supports the winding.In Fig. 202, which shows thecompleted core, the supportingrim and narrow ventilating ducts are visible. Ventilating Ducts. Armature cores, as already explained,… … Fig. 200. Construction of Armature Hub 181 172 DIRECT-CURRENT DYNAMO has been found necessary, in the large and heavy-duty types of to-day, to resort to means of ventilation, usually consisting of ductsvi^hich lead the air out between the core-disks. To keep the core-disks apart at these ducts, it…
