are illustrated in Fig. 219; whileFig. 220 illustrates a later type ofthe former, and Fig. 221 a com-pleted armature winding built upof such coils. What the Eickemeyer coil ac-complishes for the evolute winding,may be accomplished for the bar-rel winding by use of straight-out formers. Fig. 222… … Fig. 222 Straight-Out Former-WoundCoil, and Coil Opened OutI
